| General |
Diagonal size |
8″ |
| Panel type |
TFT LCD |
| Aspect ratio |
4 : 3 |
| Number of pixels |
800 x 600 |
| Pixel pitch |
0.0675 x 0.2025 mm |
| Color depth |
Full Color |
| Backlight |
LED |
| Optical (typ.) |
Brightness |
350 cd/m2 |
| Contrast ratio |
400:1 |
| Response time ( Tr + Tf) |
12 ms |
| Viewing angle |
Vertical -90°~70° / Horizontal -85°~85° |
| Operation |
Input Interface |
BNC x 1, VGA x 1, PC Audio x 1 |
| Display mode |
AV / VGA |
| OSD |
Contrast, Brightness, Colo Temp |
| OSD Languages |
English |
| Remote control |
Yes |
| Composite Video |
System |
PAL / NTSC |
| Electrical |
Power |
DC12V |
| Power consumption |
< 10W |
| Power supply |
External power adapter |
| Mechanical |
Case material |
Plastic |
| Color |
Black |
| Dimension ( W x H x D)(include stand) |
205 x 236 x 106 mm |
| Support |
Pedestal base |
| Net weight (Monitor & stand) |
0.7kgs ( 1.5 lbs ) |
| Environment |
Temperature |
Operation: 0°~40°C(32° ~104°F)Storage: -10°~60°C(14° ~140°F) |
| Humidity |
10%-90% |
| Standards |
Safety |
FCC, CE, ROHS |
| Delivery set |
|
Power cord with adapter, Video cable, Car charger, Remote, Vga cable, User manual |
| * The Specifications are subject to change without notice |
