| General |
Diagonal size |
26″ |
| Panel type |
TFT LCD |
| Aspect ratio |
16:10 |
| Number of pixels |
1920 x 1200 |
| Pixel pitch |
0.2865 x 0.2865 mm |
| Color depth |
16.7 Million Colors |
| Backlight |
CCFL |
| Optical (typ.) |
Brightness |
400 cd/m2 |
| Contrast ratio |
1000:1 |
| Response time ( Tr + Tf) |
5 ms |
| Viewing angle |
Vertical -80°~80°Horizontal -80°~80° |
| Camera Specifications |
Image Sensor |
2.8-12mm auto iris Lens |
| Effective Pixels |
NTSC: 1028(H) x 508 (V)PAL: 1024(H) x 596 (V) |
| Resolution |
Color: 680TVL |
| Min. Illumination |
0.03 Lux color ,0 Lux with IR/F1.6 |
| Wide Dynamic Range |
ATR Digital WD |
| Automatic Gain Control |
ON / OFF ( 4 Steps ) |
| Video Output |
1.0 Vp-p , 75 ohm |
| Operation |
Input Interface |
BNC x 2, VGA x 1, HDMI x 1, RCA x 2, PC Audio x 1 |
| Output Interface |
BNC x 2 |
| Display mode |
Video 1 / Video 2 / PC / HDMI |
| OSD |
Picture Mode, Contrast, Brightness, Color, Tint, Sharpness, Color Temp, DNR |
| OSD Languages |
English, German, French, Italian, Spanish, Russian, Turkish, Polish, Dutch, Czech |
| Additional modes |
No |
| Speaker |
1.5 W x 2 |
| Remote control |
Yes |
| Composite Video |
System |
PAL / NTSC |
| Video processing |
Motion Adaptive 3D De-Interlacer and DNR, 4H Comb filter Y/C separation |
| Electrical |
AC power |
AC 100-240V 50/60HZ |
| Power consumption |
100W Max. in “ON” Mode |
| Power supply |
External power adapter |
| Mechanical |
Case material |
Mental |
| Color |
Black |
| Dimension( W x H x D)(include stand) |
587 x 450 x 99 |
| Mounting interface |
200 x 100 mmor 100 x100 mm |
| Net weight(Monitor & stand) |
9.8Kgs (21.6 lbs) |
| Environment |
Temperature |
Operation: 0°~40°C(32° ~104°F)Storage: -10°~60°C(14° ~140°F) |
| Humidity |
10%-90% |
| Standards |
Safety |
FCC, CE, ROHS |
| Pixel defect policy |
ISO13406-2 Compliant, LCD panel class 2 |
| Delivery set |
|
Monitor, Power cord, VGA cable, User Manual, Remote controller |
| Options |
Wall mount |
A420/A422 |
