A09C1
* The specifications are subject to change without notice.
|
||
 |
||
| General | Diagonal size | 9.7″ |
| Panel type | TFT LCD | |
| Aspect ratio | 4:3 | |
| Number of pixels | 1024 x 768 | |
| Pixel pitch | 0.192 x 0.192 mm | |
| Color depth | 262K Colors | |
| Backlight | LED | |
| Optical (typ.) | Brightness | 400 cd/m2 |
| Contrast ratio | 1000:1 | |
| Response time ( Tr + Tf) | 4 ms | |
| Viewing angle | Vertical -89°~89°Horizontal -89°~89° | |
| Operation | Input Interface | BNC x 1, VGA x 1, HDMI x 1, USB-Video x1, USB-RCA x2, PC audio x 1 |
| Output Interface | PC audio x 1, USB-BNC x1 | |
| Display mode | Video 1 / Video 2 / VGA / HDMI | |
| OSD | Contrast, Brightness, Color, Saturation, Sharpness, Color Temp | |
| OSD Languages | English, German, French, Italian, Spanish, Russian, Polish | |
| Additional modes | No | |
| Speaker | 1.5 W x 2 | |
| Remote control | Yes | |
| Composite Video | System | PAL / NTSC |
| Electrical | AC power | AC 100-240V 50/60HZ |
| Power consumption | 15W Max. in “ON” ModeUnder 0.5W in Power Saving Mode (100 Vac)Under 0.5W in Power Saving Mode (240 Vac) | |
| Power supply | External power adapter | |
| Mechanical | Case material | Plastic |
| Color | Normally black, other colors are available(for quantity up to 200pcs per model) | |
| Dimension( W x H x D) | 266 x 193 x 39 mm | |
| Mounting interface | VESA mount 75 x 75 mm | |
| Gross weight | 2.1Kg | |
| Net weight(Monitor & Stand) | 1.2Kg | |
| Environment | Temperature | Operation: 0°~40°C(32° ~104°F)Storage: -10°~60°C(14° ~140°F) |
| Humidity | 10%-90% | |
| Standards | Safety | FCC, CE, ROHS |
| Pixel defect policy | ISO13406-2 Compliant, LCD panel class 2 | |
| Delivery set | Monitor, Adapter, Remote controller, Stand, User Manual | |
